| Specifications | UT305A+ | UT305C+ |
| Measurement range | Infrared temperature measurement | -50°C~1850°C (-58.0℉～3362℉) | -50°C~2200°C (-58.0℉～3992℉) |
| The environment temperature measurement | -10°C~50°C (14℉～122℉) |
| Relative humidity | 10%RH~90%RH |
| Type K thermocouple | -50°C~1370°C (-58.0℉～2498℉) |
| Accuracy | Infrared temperature measurement | -50°C~0°C, ±(1.0℃+0.1℃/℃) -58℉~32℉, ±(2.0℉+0.1℉/℉) 0°C~2200°C, ±1.0℃ or ±0.01×t℃ (Which is greater)
32℉~3992℉, ±2.0℉ or ±0.01×t℉ (Which is greater) |
| The environment temperature measurement | -10°C~0°C (14℉~32℉), ±1.0°C (±2.0℉) 0°C~40°C (32℉~104℉), ±0.5℃ (±1.0℉) 40°C~50°C (104℉~122℉), ±1.0℃ (±2.0℉ ) |
| Relative humidity | ±5%RH |
| Type K thermocouple | ±(0.005×t+1.5)℃, ±(0.005×t+3.0)℉ |
| Certification | CE UKCA |
| Diastance ratio(D:S) | 55:1 |
| Emissivity | 0.1~1.0 (adjustable) |
| Spectral response | 8µm~14µm |
| Repeatability of infrared temperature measurement | ±0.005×t℃(℉)or 1℃(2℉) (Which is greater) |
| Display resolution | 0.1℃(0.1℉) |
| Unit conversion | ℃ / ℉ |
| Laser point | Single laser, output < 1 mW, class II |
| Data storage | 999 groups |
| Data output format | PDF,CSV |
| Data communication or charging interface | Type-C USB |
| Battery | Li-ion 3.7V 2600mAh 18650 rechargeable lithium-ion battery |
| Charging time | No more than 3 hours |
| Continuous working time | Work continuously for no less than 20 hours on full charge |
| Buzzer alarm | √ |
| Trigger lock function and reservation measurement | √ |
| Real time, date | √ |
| LCD type | 2.4 inch TFT LCD 320 * 240 pixels |
| temperature coefficient | ±0.1℃/℃ or ±0.1%℃/℃, ±0.1℉/℉ or ±0.1%℉/℉(Which is greater) |
| Work at an altitude of | No more than 2000 meters |
| Drop test | 1m |
| Standard k-type thermocouple probe (bead type) |
| Measurement range | -40°C to 260°C (-40°F to 500°F) |
| Accuracy | 0.075× T (t is measured temperature) |
| Lenth | 1 m (40 in) long K type thermocouple cable with standard micro thermocouple connector and bead probe |
| General Characteristics |
| Power | Li-ion 3.7V 2600mAh 18650 rechargeable lithium-ion battery |
| LCD screen size | 37mm x 49mm |
| Product color | red and gray |
| Net weight | 375 g |
| Product size | 205 x 65 x 124 mm |
| Standard accessories | Type-C data cable, Type K thermocouple probe (bead Type) |
| Standard packing | Gift box, tool box, instruction manual, warranty card |
| Standard packing quantity | 1 pc |
| Standard packing size | 365*160*300 mm
|
